2.7.3: Fruits and Dispersal

Learning Objectives

• Describe the transition from ovary and ovule to fruit and seed.
• Use characteristics of fruits, including pericarp morphology, to identify fruit type.
• Use characteristics of fruits to predict the dispersal agent for a plant's seeds.

All flowers become fruits (Figure \(\PageIndex{1}\)). This may be surprising at first, as what we culturally refer to as a fruit is a bit different than the botanical definition. Many of the "vegetables" and other plant products (e.g. grains, legumes, and nuts) that you get from the store are actually fruits! The term angiosperm refers to the fruit: angio- means vessel and sperm refers to the seed; fruits are the vessel that houses the seed or seeds. Fruits are a development of the ovary wall and sometimes other flower parts. As seeds mature, they release the hormone auxin, which stimulates the wall of the ovary to develop into the fruit. In fact, commercial fruit growers may stimulate fruit development in unpollinated flowers by applying synthetic auxin to the flower. This chapter section will cover the anatomy of a fruit, including the ovary, different fruit types, and finally, how these fruits are specialized for different dispersal mechanisms.



Figure \(\PageIndex{1}\): These two images show clusters of pear blossoms from the same tree. The cluster on the left is in an earlier stage of development. The corolla is still attached and the stamens are radiating outward to disperse pollen. In the image on the right, the corolla has fallen off and the anthers have shriveled. The calyx is still visible and, just below it, the semi-inferior ovary and hypanthium are beginning to swell. Eventually, these will swell to many times their current size and form the fruits we know as pears. Photos by Maria Morrow, CC-BY 4.0.

A fruit is defined as ripened ovary, flower, or whole inflorescence. Depending on how these parts interact to form the fruit, we can classify them into different fruit types. The pericarp (Figure \(\PageIndex{2}\)), which is comprised of the exocarp, mesocarp, and endocarp, is derived from the ovary wall.



Figure \(\PageIndex{2}\): Two fruits with different pericarp morphology. The pericarp of a fruit can be separated into distinct layers, as in the first photo, or completely fused together, as in the second photo. The first photo shows a peach, which is a type of fruit called a drupe. It has a stony endocarp enclosing a single seed, a fleshy mesocarp, and a thin exocarp. The second photo shows a corn kernel, which is a type of fruit called a caryopsis. In this fruit type, the pericarp (A) is thin, layers are indistinguishable, and it is completely fused to the seed coat. First mage by LadyofHats, Public domain, via Wikimedia Commons. Second image by Jon Houseman, CC BY-SA 4.0, via Wikimedia Commons. Labels are as follows: A=Pericarp, B=Aleurone, C=Tip cap, D=Endosperm, E=Coleorhiza, F=Radicle, G=Hypocotyl, H=Plumule, I=Scutellum, J=Coleoptile. Scale=1.4mm.

Ovary Anatomy

An unfertilized ovary, as shown in Figure \(\PageIndex{3}\), contains one or more developing ovules produced in compartments called locules. Within the ovule, the megasporangium is surrounded by tissue within the called the integument. Both of these are diploid tissues of the sporophyte. A diploid megaspore mother cell is produced within the megasporangium, which will divide by meiosis to produce the haploid megagametophyte (see Chapter 7.3.2: Angiosperm Life Cycle for a refresher). Each ovule is attached to a nutritional region of the ovary called the placenta by a strand of tissue called the funiculus. The sporophyte supports the developing ovule through this tissue pathway. Prior to fertilization, there is a small gap in the integument called the micropyle.

Figure \(\PageIndex{3}\): Cross section of Lilium ovary, showing A=Female gametophyte, B=Ovule, C=Locule, D=Placenta, E=Dissepiment. The ovary has three locules, each with two developing ovules. Each ovule attached to the ovary by a region of tissue called the placenta. The ovary wall will develop into the fruit and the ovules will develop into seeds, if fertilized. The label in red added to original contribution of File:Lilium ovary L.jpg provided by Jon Houseman and Matthew Ford. JonRichfield, CC BY-SA 4.0, via Wikimedia Commons.

After fertilization, ovules become seeds. The micropyle closes and the integument becomes the seed coat. The megasporangium, called the nucellus, serves as nutritive tissue for the developing embryo. Angiosperms provide an additional food source to the developing zygote, the endosperm. The ovary wall develops into the pericarp.

Fruit Types

Fruits may be classified as simple, aggregate, multiple, or accessory, depending on their origin (Figure \(\PageIndex{11}\)). If the fruit develops from a single carpel or fused carpels of a single ovary, it is known as a simple fruit, as seen in nuts and beans. An aggregate fruit is one that develops from more than one carpel, but all are in the same flower: the mature carpels fuse together to form the entire fruit, as seen in the raspberry. A multiple fruit develops from an inflorescence or a cluster of flowers. An example is the pineapple, where the flowers fuse together to form the fruit.

Fruits can be dry or fleshy. An example of dry fruit is a peanut (Arachis), the shell of the peanut is the pericarp, which is dry at maturity. Examples of fleshy fruits include apples (Malus) or oranges (Citrus), where the pericarp or some other part of the floral structure becomes swollen with liquid.

Dry fruits can be further classified into dehiscent fruits, which open at maturity, or indehiscent fruits, which do not open independently. Schizocarp fruits are in between: they do not open but break into several parts (usually the distinct locules), and each part contains one seed inside. For example, maple fruit consists of two “wings”, each of them contains part of the full fruit and one seed.

In addition, fruits can be monomerous (1-seeded) like a nut or an achene, or bear multiple seeds (like the follicle in a tulip, Tulipa).

Accessory Fruits

Accessory fruits (sometimes called false fruits) are not derived from the ovary, but from another part of the flower, such as the receptacle (Figure \(\PageIndex{4}\)) or the hypanthium (Figure \(\PageIndex{5}\)).



Figure \(\PageIndex{4}\): Strawberries are accessory fruits formed from a swollen receptacle. The receptacle reddens and swells, pushing the developing fruits outward. The fruits are achenes that look like seeds, stuck to the outside of the receptacle. If you look closely, you can see the styles attached to the narrow end of each achene, each with a stigma at the end. Because strawberries are formed from multiple free carpels, they are also an aggregate fruit. In the second image, the green layer is the calyx. First strawberry photo by Troy Pemberton (found on Instagram as Infinitesimal Prints), used with permission. Sliced strawberry photo by Paolo Neo, Public domain, via Wikimedia Commons.

Figure \(\PageIndex{5}\): A pome is an accessory fruit made from a fleshy hypanthium. The papery core is the pericarp, which contains the seeds. Eric Guinther, CC BY-SA 3.0, via Wikimedia Commons.

Dichotomous Key to Common Fruits

Use the following dichotomous key to identify fruit types! Note: If the fleshy part of the fruit is composed of something other than the ovary, it is an accessory fruit.

1. Fruit from one carpel of one flower ........[Simple Fruit].... 2

1. Fruit from more than one carpel or from an inflorescence .... 16

2. Fleshy at maturity ....................................... 3

2. Dry at maturity ............................................ 8

3. Thin exocarp, fleshy mesocarp, stony endocarp surrounding single, large seed ............... Drupe

3. Fruit not as described above............................................................................................... 4

4. Seeds in a linear order, separate from ovary wall, pericarp splits on two seams ...Legume (immature)

4. Fruit not as described above.................................................................................. 5

5. Papery endocarp forms a core. Derived from a perigynous flower..........Pome

5. Endocarp fleshy (not a papery core) ...................................................... 6

6. Thin exocarp, fleshy mesocarp, one to many seeds ........................... Berry

6. Exocarp thickened and leathery (modified berries) ………......... 7

7. Exocarp and mesocarp form leathery rind, locules filled with juice-filled trichomes ……...Hesperidium

7. Exocarp forms tough skin/rind, thick mesocarp, not divided into separate locules ........... Pepo

8. Dehiscent (splits open at maturity), usually many seeds ....... 9

8. Indehiscent (does not split open), usually one seeded .......... 12

9. Derived from a carpel with one locule ............................. 10

9. Derived from a carpel with more than one locule ............ 11

10. Dehiscent along one seam .......................... Follicle

10. Dehiscent along two seams ........................ Legume

11. From two locules with a central partition .............. Silique (elongate) or silicle (round)

11. From more than two locules.................................. Capsule

12. Ovary wall extends to form a wing .................. Samara

12. Fruit not winged ............................................... 13

13. Outer wall not especially thick or hard, seed small ... 14

13. Outer wall hardened, seed relatively large ................ 15

14. Seed not tightly attached to pericarp ............... Achene

14. Seed fused to pericarp, grains ........................ Caryopsis

15. Stony pericarp surrounds one large seed .............................................. Nut

15. Relatively thin exocarp, fibrous mesocarp, single large seed .............. (dry) Drupe

16. Derived from one flower with many free carpels ...... Aggregate Fruit

16. Derived from an inflorescence (many florets) ........... Multiple Fruit

Fruit and Seed Dispersal

The fruit has a single purpose: seed dispersal. Seeds contained within fruits need to be dispersed far from the mother plant, so they may find favorable and less competitive conditions in which to germinate and grow. Fruits promote the dispersal of their content of seeds in a variety of ways:

• Ballistic. Some fruits, as they dry, open explosively expelling their seeds. The pods of many legumes (e.g., wisteria) do this.
• Wind. Wind-dispersed fruit are lightweight and may have wing-like appendages that allow them to be carried by the wind. Some have a parachute-like structure to keep them afloat.
• Water. Many aquatic angiosperms and shore dwellers (e.g., the coconut palm) have floating fruits that are carried by water currents to new locations.
• Animal attachment. The cocklebur and sticktights achieve dispersal of their seeds by sticking to the coat (or clothing) of a passing animal.
• Animal ingestion. Nuts and berries entice animals to eat them. Buried and forgotten (nuts) or passing through their g.i. tract unharmed (berries), the seeds may end up some distance away from the parent plant.

All of the above mechanisms allow for seeds to be dispersed through space, much like an animal’s offspring can move to a new location. Seed dormancy allows plants to disperse their progeny through time: something animals cannot do. Dormant seeds can wait months, years, or even decades for the proper conditions for germination and propagation of the species. These dormant seeds can accumulate in the soil, forming a seed bank. Areas prone to disturbances, like fire, often rely on the seed bank to regenerate plant communities post-disturbance.

Ballistic

In ballistic dispersal, seeds are shot from the fruit. This can be accomplished via a build up of turgor pressure within the fruit (as in dwarf mistletoe and wild cucumber), a twisting action, or some other method. Watch Video \(\PageIndex{1}\) to see ballistic seed dispersal in action!

Video \(\PageIndex{1}\): Watch this fun video of different plants utilizing ballistic seed dispersal. Sourced from YouTube.

Wind

Fruits dispersed by wind, like samaras or the achenes of a dandelion, are generally winged (Figure \(\PageIndex{6}\)). In the case of a dandelion, each achene is attached to a modified calyx that forms an umbrella-like structure to catch on the wind.



Figure \(\PageIndex{6}\): Samaras are winged achenes adapted to wind dispersal. The maple samaras on the left are also schizocarps, breaking apart at maturity into two separate fruits. Left image by Gmihail at Serbian Wikipedia, CC BY-SA 3.0 RS, via Wikimedia Commons. Right image by Marco Schmidt [1], CC BY-SA 3.0 via Wikimedia Commons.

Water

Some fruits, such as those of some aquatic plants like lotus or plants adapted to island living, are specialized for water dispersal. This usually involves a buoyant pericarp, as in the fibrous husk of the water-dispersed coconut. Similarly, willow and silver birches produce lightweight fruit that can float on water. Watch Video \(\PageIndex{2}\) to see the journey of a water-dispersed sea bean.

Video \(\PageIndex{2}\): Watch this clip to see the aquatic journey of the sea bean. Toward the end of the video, be on the lookout for mangrove pneumatophores. Sourced from YouTube.

Animal Vectors

Many fruits have evolved to use animals for dispersal. Fruits with velcro-like projections or sticky pericarps latch onto mammal fur or bird feet and are transported to a new locale without needing to survive a journey through the digestive tract (Figure \(\PageIndex{7}\)). Other fruits have specialized for animal ingestion. Among these are the fruits we typically consider fruits, those that are typically sweet, fleshy, often brightly colored and intended for consumption. The seeds must either survive the digestive tract, deposited later in nutrient-rich substrate, or depend on animals who are sloppy eaters, dispersing some of the seeds as they eat others.

Some of these are highly specialized, with a single species or group of animals as the intended dispersal vector. For example, hot peppers like habañero chiles are hot because they contain a compound called capsaicin (see Figure \(\PageIndex{8}\)). They also tend to be red. This is because these peppers have specialized for bird dispersal vectors. Both birds and mammals are attracted to the color red. However, mammals often have a more thorough digestive tract, meaning seeds need more investment in protection to survive the journey. However, mammals like you and I interpret capsaicin as spicy, perhaps painful, and are often deterred by it (though many exceptions apply among humans), while birds are immune to these effects. Because of this interesting difference in physiology, some people add cayenne pepper to their suet bird feeders to keep the squirrels away.

Some animals, like squirrels, bury seed-containing fruits for later use; if the squirrel does not find its stash of fruit, and if conditions are favorable, the seeds germinate. Some birds are also known to cache nuts for later. Plants that produce nuts generally rely on this storage behavior in their animal dispersers.

Figure \(\PageIndex{7}\): Animal attachment. Fruits of Xanthium, cockleburrs, have hooked spikes that allow them to attach to passing animals. Photo by Muséum de Toulouse, CC BY-SA 3.0 via Wikimedia Commons.

Figure \(\PageIndex{8}\): Habañero chiles (and other spicy peppers) have specially adapted for bird dispersal. They contain a compound called capsaicin that is incredibly spicy to most mammals but does not bother birds. Photo from The original uploader was Fir0002 at English Wikipedia., CC BY 2.5 via Wikimedia Commons.
